Spectropho tometer Easy VIS
Mettler Toledo
Contact a technical expert | Dowload the datasheet
Your Compact Vis Spectrophotometer.
Easy VIS provides an economic option for the spectrophotometric analysis using visible light, and an easy-to-replace lamp module for self-maintenance.
Advantages
- Conventional Spectrophotometry
Run a photometric measurement at multiple wavelengths or scan a spectrum of the sample with customizable parameters and the peak-finding function. - Color Measurement
30 standard-compliant ready to use color scales (e.g. CIELAB, APHA, Gardner) shorten the time to result and avoid calculation errors. - Water Testing
The SQKitReader™ option enables your Easy UV to read the barcode of Spectroquant® water test kits and start the built-in methods.
Measurement versatility
Conventional spectrophotometry, color measurements, and water analyses can be performed using one instrument.
This saves bench space and reduces your investment in equipment and service. Exchangeable XPathHolders™ allow youto shift quickly between seven differentpath lengths to suit a wide applicationand concentration range.
Efficient accuracy
Photometric data is automatically calculated using pre-programmed methods so you obtain results quickly (e.g. concentration or tristimulus values). Methods that are compliant to standards such as ASTM, DIN, ISO, and EPA eliminate the need for post-measurement calculation and data transcription to achieve accurate results efficiently.
Intuitive operation
The intuitive user interface with workflow guidance and integrated tutorials allow you to simply plug-and-measure.
Additional functions such as closing the SmartLid ™ to automatically start the measurement, increase productivity, and avoid time-consuming task repetition
Wavelength Range (nm) | 330 nm – 1,000 nm |
Photometric accuracy (K2Cr2O7) | ±0.005 A |
Wavelength accuracy | ±1.5 |
Options | USB transfer cable EasyDirect™ Cuvettes Handheld barcode scanner SQKitReader™ Printer USB-P25 |
Shortcuts per user | 10 |
Max. number of methods | 80 |
Languages | English Italian Polish French Portuguese Bahasa Indonesia Korean Chinese German Spanish Thai Japanese |
Dimensions (HxWxD) | 176 mm x 201 mm x 362 mm |
Weight (incl. Terminal) | 4.25 kg |
Cuvette Changer | No |
Optics | Scanning |
Light Source | Tungsten lamp |
Connectivity USB Interface | Yes |
Protection Class | IP31 |
Application | Water Color Scan Quant |
Material Number(s) | 30705170 |
