XRF Spectrometer Revontium
Malvern panalytical
Compact Engineering, Powerful Analysis, Infinite Possibilities
The Revontium™ is a compact X-ray Fluorescence (XRF) analyzer that delivers high-quality elemental analysis in a benchtop format. It combines the performance of floor-standing XRF systems with the versatility of benchtop instruments.
Advantages
The Revontium ensures enduring precision by capturing every signal in your X-ray fluorescence spectrum, leveraging meticulous design and high-quality hardware and software components.
Ultimate Efficiency: With the Revontium, you can rely on swiftly obtaining high-quality results. The instrument is engineered for high throughput analysis, rapid analysis, and active feedback.
Low Cost of Ownership: Operating in ambient air reduces the need for consumables such as acids and high-purity gases. It eliminates the requirement for daily calibration, coolers, or special infrastructure, maximizing time available for actual analysis.
Total Flexibility: The Revontium handles nearly all types of XRF applications. It can analyze both solids and liquids within the same batch of samples, and optional Omnian software is compatible with any sample type.
Low Environmental Footprint: With numerous sustainable features, the Revontium consumes only 200 watts of energy.
Ease of Use: Large tactile buttons, an intuitive display screen, and a 15-inch touchscreen ensure smooth operation.
Sample Handling:
- Sample Loading: Sample loading via robotic arm
- Sample Holder: Supports samples up to 52 mm in diameter
- Sample Passage: Robotic arm facilitates sample passage
- Sample Preparation: Handles solids, liquids, and powders as-is—no acids required
- Automation: Coming soon
X-ray Tube:
- Excitation: 4 to 60 kV
- Drift: Minimal drift due to Zero-Evaporation Technology Advancement (ZETA)
- Manufacture: Made in Eindhoven, Netherlands
- Operating Temperature: 10 to 30 °C
- Sensitivity: 50 um thin window for improved light element sensitivity
- Protection: Chi-blue coating protects against spills
Detector:
- Photon Count: 6 million photons per second at 50% dead time
- Power Consumption: 200 W
General:
- Dimensions (H x W x D): 70 x 60 x 38 cm (or 56 cm H with sample handler)
- Dust Protection: Available inside and outside the instrument
- External Cooling: Not required
- Compressed Air Supply: Not required
- Power Supply: 100 to 240 V
- Computer: Internal computer with Windows operating system
- User Interface: Intuitive interface with 15-inch touchscreen
- Ports: 4 USB ports
- Academic Research
- Construction Materials
- Environmental Monitoring
- Food and Non-Food Products
- Metals
- Mining and Minerals
- Petrochemicals
- Pharmaceuticals
- Polymers and Plastics
